C |
Mn |
Cr |
P |
S |
Mo |
Ni |
Nitrogen |
Si |
Iron |
≤0.02 |
≤2.0 |
24.0-26.0 |
≤0.025 |
≤0.01 |
2.0-2.5 |
21.0-23.0 |
0.1-0.16 |
≤0.7 |
Bal |
Chemical Composition
Mechanical Properties
Tensile Strength(Mpa)) |
Yield Strength, Mpa |
Elongation % |
Hardness, Brinell |
540-740 |
≥250 |
40 |
95 |
Standard
ASTM A213 / ASME SA213
ASTM A312 / ASME SA312
Material Summary
310moln stainless steel grade is a fully austenitic stainless steel that does not have intermetallic phases such as intergranular carbide precipitations. For applications in urea plants 310MoLN steel grade has a specififically designed optimized chemical composition. To stabilize and strengthen the austenitic phase the nitrogen in the chemical composition helps. 310 MoLN, material gives excellent corrosion-resistance in urea carbamate environments such as high-pressure strippers. Among wrought austenitic stainless steels it has a fairly high base cost. And it has a fairly high embodied energy and a fairly low ductility.
