ASTMA213 Stainless Steel Seamless U Tube

ASTMA213 Stainless Steel Seamless U Tube

ASTMA213 Stainless Steel Seamless U Tube

Seamless Stainless Steel U-tube is a specific type of heat exchanger tube that is bent into a"U"shape after the manufacturing process. It is crafted from a single, solid billet of stainless steel and, like other seamless tubes, has no weld joint. This seamless construction is crucial for maintaining structural integrity and reliability, especially in high-stress and corrosive environments. The unique U-shape allows for thermal expansion and contraction, making it ideal for shell and tube heat exchangers. It enables a single-pass fluid flow on the shell side and a multi-pass flow on the tube side, maximizing heat exchange efficiency and reducing the overall footprint of the heat exchanger.

① STANDARD: ASTM A213

② OD RANGE : 6-50.8MM

③ THICKNESS RANGE: 0.5-9MM

④ U-BEND & STRAIGHT

Material Summary


Seamless Stainless Steel U-tube is a specific type of heat exchanger tube that is bent into a"U"shape after the manufacturing process. It is crafted from a single, solid billet of stainless steel and, like other seamless tubes, has no weld joint. This seamless construction is crucial for maintaining structural integrity and reliability, especially in high-stress and corrosive environments. The unique U-shape allows for thermal expansion and contraction, making it ideal for shell and tube heat exchangers. It enables a single-pass fluid flow on the shell side and a multi-pass flow on the tube side, maximizing heat exchange efficiency and reducing the overall footprint of the heat exchanger.

Seamless Stainless Steel U-tubes offer a unique combination of benefits that make them invaluable in demanding heat transfer applications:

Superior Heat Transfer Efficiency: The U-shape design allows for multiple passes within the same shell, significantly increasing the effective surface area for heat exchange and improving thermal efficiency.

High Pressure and Temperature Tolerance: The seamless construction and robust material allow the tube to safely handle high internal pressures and extreme temperatures without the risk of rupture, ensuring operational safety.

Exceptional Corrosion Resistance: Stainless steel's inherent properties provide outstanding resistance to oxidation, pitting, and crevice corrosion, ensuring a long service life even in harsh chemical environments.

Enhanced Durability: The absence of a weld seam eliminates a potential weak point, making the tube more durable and reliable under mechanical stress and vibration.

Reduced Footprint: The compact U-tube design allows for a more efficient and space-saving heat exchanger configuration compared to straight-tube designs with similar heat exchange capacity.



Heat Exchanger Applications

Heat exchanger is a device used to transfer heat between a solid object and a fluid, or between two or more fluids at different temperatures, transfer heating from higher temperature fluid to lower temperature object to make fluid temperature to specified requirement, for stainless steel grades, there are shell and tube heat exchanger, plate heat exchangers, plate and shell heat exchanger and other heat exchanger, tube heat exchanger consists of a number of tubes inside bundle and sheet, widely used in many industries.

  • Space Heating
  • Refrigeration
  • Air Conditioning
  • Power Stations
  • Chemical Plants
  • Petrochemical Plants
  • Petroleum Refineries
  • Natural-Gas Processing
  • Wine And Beer Making

American Standard

Austenitic Steel:

TP304, TP304L, TP304H, TP304N, TP310S, TP316, TP316L, TP316Ti, TP316H, TP317, TP317L, TP321, TP321H, TP347, TP347H,904L…

Duplex Steel:

S32101, S32205, S31803, S32304, S32750, S32760

Others:TP405,TP409, TP410, TP430, TP439,...

European Standard

1.4301, 1.4307, 1.4948, 1.4541,1.4878, 1.4550, 1.4401, 1.4404, 1.4571, 1.4438,  1.4841, 1.4845, 1.4539, 1.4162, 1.4462, 1.4362, 1.4410, 1.4501

ASTMA213 size tolerance chart

Size Tolerance

Tube Kinds

SA213 OD(D)

SA213 Thickness(S)

OD(mm)

OD Tolerance(mm)

OD(mm)

Thickness Tolerance(mm)

Hot Rolled

=101.6

+0.4~-0.8

76~168.3

+28%~0

>101.6~168.3

+0.4~-1.2

Cold Drawn

<25.4

0.1

=38.1

+20%~0

25.4~38.1

0.15

>38.1~<50.8

0.2

>38.1

+22%~0

50.8~<63.5

0.25

63.5~<76.2

0.3

76.2~101.6

0.38

Size Range

Production

Outside Diameter

Wall Thickness

Heat Exchanger Tube

6.00mm -203.2mm

0.5mm - 21mm

Final Finishing

Solution Annealed & Pickled/Bright Annealed.

One of our Services--Testing

  • EN 10204/3.1B, EN 10204 3.1 and EN 10204 3.2 Material Test Certificates (MTC)
  • Raw Materials Certificate
  • 100% Radiography Test Report
  • 100% PMI
  • Heat Treatment Charts
  • Third Party Inspection Report
  • Surface roughness and size measurement
  • Manufacturer Test Certificate( Impact Testing, Flatten, Spin,Curve, Hardness, Intergranular ,Point corrosions, Grain size, ET,UT, HT...)
  • Laboratory Test Certificate from Govt. Approved Lab
  • ......
