ASTMB622 ASTMB829 Hastelloy B2/UNS N10665/2.4617 Seamless Nickel Alloy Steel Tube

Hastelloy B2, also known as UNS N10665, is a nickel-molybdenum alloy with high levels of chromium and molybdenum. Its exceptional properties make it suitable for various industrial applications. Let’s explore how it is used in different industries:

1. Chemical Processing:
• Hastelloy B2 is widely employed in chemical processing equipment due to its excellent corrosion resistance against a wide range of organic and inorganic acids.
• It finds applications in reactors, heat exchangers, and other components exposed to aggressive chemical environments.
2. Oil and Gas Industry:
• In the oil and gas sector, Hastelloy B2 is used in sweetening units, sour gas wells, and offshore platforms where corrosion resistance is essential.
• Its ability to withstand harsh conditions makes it valuable in these applications.
3. Pharmaceutical Industry:
• Hastelloy B2 is employed in pharmaceutical equipment due to its corrosion resistance and formability.
• It ensures product purity and safety in critical processes.
4. Power Generation:
• The alloy is used in power plants for components like de-aerating heaters.
• Its good oxidation resistance at high temperatures contributes to efficient operation.
5. Marine Engineering:
• In marine applications, Hastelloy B2 is suitable for marine fixtures, bimetal contacts, and gasoline and freshwater tanks.
• Its corrosion resistance ensures longevity in saltwater environments.

Remember that Hastelloy B2’s versatility and superior properties make it an ideal choice for demanding environments across various industries.

• EN 10204/3.1B, EN 10204 3.1 and EN 10204 3.2 Material Test Certificates (MTC)
• Raw Materials Certificate
• 100% Radiography Test Report
• 100% PMI
• Heat Treatment Charts
• Third Party Inspection Report
• Surface roughness and size measurement
• Manufacturer Test Certificate( Impact Testing, Flatten, Spin,Curve, Hardness, Intergranular ,Point corrosions, Grain size, ET,UT, HT...)
• Laboratory Test Certificate from Govt. Approved Lab
• ........

• BE : Beveled end
• BBE : Bevel both ends
• BLE : Bevel large end
• BSE : Bevel small end
• TOE / POE = Treaded One End / Plain One End
• TOE / BOE = Treaded One End / Beveled One End
• POE / BOE = Plain One End / Beveled One End
• TBE = Treaded Both Ends
• PBE = Plain Both Ends

• Ply Wooden Boxes
• PE Fabric Bundles
• Standard seaworthy export packing
• Plastic Bags, or as required

• Supplier / Manufacturer Name or Custom Logo - on request
• Specification
• Material Grade
• Nominal Size
• Schedule or Wall Thickness
• Method of Manufacturing (Seamless or Welded)
• Heat Number

Marked Pipe Sample: XTD ASTM B622 UNS N10665 SEAMLESS 42.2x 3.56*6000MM HEAT NO. 2023121205A15

Alloy B2 Pipes and Tubes is a solid solution strengthened, nickel-molybdenum alloy, typically used in extreme reducing conditions. UNS N10665 Pipes and Tubes has significantly lower carbon, silicon and iron compared to its’ predecessor, Alloy B (UNS N10001), making the alloy less susceptible to decreased corrosion resistance in the weld zone, in the as-welded condition.

Alloy B2 is a nickel-molybdenum alloy with significant resistance to reducing environments, such as hydrogen chloride gas and sulphuric, acetic and phosphoric acids. Hastelloy B2 provides resistance to pure sulphuric acid and a number of non-oxidizing acids. The alloy should not be used in oxidizing media or where oxidizing contaminants are available in reducing media. Premature failure may occur if alloy B2 is used where ferric iron, cupric ion and free chlorides are present.

With a high nickel content, Hastelloy B2 is immune to chloride-induced stress corrosion cracking.

ASTM B622 Standard Specification for Seamless Nickel and Nickel Cobalt Alloy Pipe and Tube

ASTMB829-Standard Specification for General Requirements for Nickel and Nickel Alloys Seamless Pipe and Tube
