Manufacture of stainless steel ,duplex & super duplex stainless,Nickel Alloy steel pipe and tube.Incoloy ,Hastelloy ,Monel ,Hastelloy seamless tube and pipe.

ASTMB622 ASTMB829 Hastelloy B3/Alloy B3/ UNS N10675/2.4600 Seamless Nickel Alloy Steel Tube

HomeProducts & servicesNickel Alloy---Hastelloy/ Monel/ Inconel/Incoloy Steel tube and Pipe ASTMB622 ASTMB829 Hastelloy B3/Alloy B3/ UNS N10675/2.4600 Seamless Nickel Alloy Steel Tube
ASTMB622 ASTMB829 Hastelloy B3/Alloy B3/ UNS N10675/2.4600 Seamless Nickel Alloy Steel Tube

ASTMB622 ASTMB829 Hastelloy B3/Alloy B3/ UNS N10675/2.4600 Seamless Nickel Alloy Steel Tube

① STANDARD: ASTM B622/ ASTM B829 ...

② OD RANGE : 6-257 MM

③ THICKNESS RANGE: 1-35 MM

Hastelloy B3/Alloy B3/ UNS N10675/2.4600 Chemical Composition

Grade
Ni
Cr
Mo
Fe
W
C
Si
Co
Mn
V
P
Ti
Cu
Al
Zr
Cb(Nb)
Ta
Ni+Mo
N10675
≥65.00
1.00-3.00
27.00-32.00
1.00-3.00
≤3.00
≤0.01
≤0.10
≤3.00
≤3.00
≤0.20
≤0.03
≤0.20
≤0.20
≤0.50
≤0.10
≤0.20
≤0.20
94.00-98.00

Hastelloy B3/Alloy B3/ UNS N10675/2.4600 Mechanical Properties

Grade

Tensile Strength ksi(MPa)

Yield Strength ksi(MPa)

Elongation(%)

N10675

≥110(760)

≥(350)

≥40

the ASTM B622 Nickel alloy seamless tube and pipe tolerance

Hastelloy B3/Alloy B3/ UNS N10675/2.4600 Applications

Hastelloy B3 is a nickel-molybdenum alloy that is highly resistant to corrosion by reducing atmospheres, such as hydrogen chloride gas and sulfuric acid. It contains a higher concentration of chromium and molybdenum, making it more resistant to pitting and crevice corrosion in chloride-containing environments.

  • - Chemical processing and production of pharmaceuticals, pesticides, and synthetic fibers
  • - Production of acetic acid, vinyl chloride monomer, and hydrogen fluoride
  • - Gas scrubbers, heat exchangers, and evaporators in marine environments
  • - Equipment for flue gas desulfurization systems
  • - Nickel wetted parts in chlorine dioxide bleach plants
  • - Digesters and bleach plants in paper and pulp industries
  • - Scrubbers and cooling towers in power plants.

One of our Services--Testing

  • EN 10204/3.1B, EN 10204 3.1 and EN 10204 3.2 Material Test Certificates (MTC)
  • Raw Materials Certificate
  • 100% Radiography Test Report
  • 100% PMI
  • Heat Treatment Charts
  • Third Party Inspection Report
  • Surface roughness and size measurement
  • Manufacturer Test Certificate( Impact Testing, Flatten, Spin,Curve, Hardness, Intergranular ,Point corrosions, Grain size, ET,UT, HT...)
  • Laboratory Test Certificate from Govt. Approved Lab
  • ........

One of our Services--End of Pipe and Tube

  • BE : Beveled end
  • BBE : Bevel both ends
  • BLE : Bevel large end
  • BSE : Bevel small end
  • TOE / POE = Treaded One End / Plain One End
  • TOE / BOE = Treaded One End / Beveled One End
  • POE / BOE = Plain One End / Beveled One End
  • TBE = Treaded Both Ends
  • PBE = Plain Both Ends

One of our Services--Packing

  • Ply Wooden Boxes
  • PE Fabric Bundles
  • Standard seaworthy export packing
  • Plastic Bags, or as required

One of our Services--Marking

  • Supplier / Manufacturer Name or Custom Logo - on request
  • Specification
  • Material Grade
  • Nominal Size
  • Schedule or Wall Thickness
  • Method of Manufacturing (Seamless or Welded)
  • Heat Number

Marked Pipe Sample: XTD ASTM B622 UNS N10675 SEAMLESS 42.2x 3.56*6000MM HEAT NO. 2023121205A15


Hastelloy B3/Alloy B3/ UNS N10675/2.4600 Material Summary

HASTELLOY B3 alloy (UNS N10675) is an excellent resistance alloy to hydrochloric acid at all concentrations and temperatures. It also withstands sulfuric, acetic, formic and phosphoric acids, and other nonoxidizing media. B3 alloy has a special chemistry designed to achieve a level of thermal stability greatly superior to that of its predecessors, e.g. HASTELLOY B2 alloy. B3 alloy has excellent resistance to pitting corrosion, to stress-corrosion cracking and to knife-line and heat-affected zone attack.

Hastelloy B3 is a nickel-based alloy with excellent corrosion resistance and resistance to stress corrosion cracking. Its main components include nickel, molybdenum, iron, chromium and other elements. Hastelloy B3 seamless pipe is a common form of Hastelloy B-3 material, which is widely used in chemical industry, aerospace, marine engineering and other fields.
