C |
Si |
Mn |
P |
S |
Cr |
Mo |
Ni |
Ti |
Cu |
Co |
Fe |
|
≤0.015 |
≤0.08 |
≤1.00 |
≤0.025 |
≤0.015 |
14.00-18.00 |
14.00-17.00 |
Bal |
≤0.70 |
≤0.50 |
≤2.00 |
≤3.00 |
C-4 2.4610 NiMo16Cr16Ti N06455 Chemical Composition
C-4 2.4610 NiMo16Cr16Ti N06455 Mechanical Properties
|
Yield strength Rp ≥N/mm² |
Tensile strength Rm ≥ N/mm² |
Elongation A5≥ % |
Modulus of elasticity kN/mm² |
|
305 |
700 |
40 |
211 |
One of our Services--End of Pipe and Tube
- BE : Beveled end
- BBE : Bevel both ends
- BLE : Bevel large end
- BSE : Bevel small end
- TOE / POE = Treaded One End / Plain One End
- TOE / BOE = Treaded One End / Beveled One End
- POE / BOE = Plain One End / Beveled One End
- TBE = Treaded Both Ends
- PBE = Plain Both Ends
One of our Services--Testing
- EN 10204/3.1B, EN 10204 3.1 and EN 10204 3.2 Material Test Certificates (MTC)
- Raw Materials Certificate
- 100% Radiography Test Report
- 100% PMI
- Heat Treatment Charts
- Third Party Inspection Report
- Surface roughness and size measurement
- Manufacturer Test Certificate( Impact Testing, Flatten, Spin,Curve, Hardness, Intergranular ,Point corrosions, Grain size, ET,UT, HT...)
- Laboratory Test Certificate from Govt. Approved Lab
- ..............
One of our Services--Packing
- Ply Wooden Boxes
- PE Fabric Bundles
- Standard seaworthy export packing
- Plastic Bags, or as required
One of our Services--Marking
- Supplier / Manufacturer Name or Custom Logo - on request
- Specification
- Material Grade
- Nominal Size
- Schedule or Wall Thickness
- Method of Manufacturing (Seamless or Welded)
- Heat Number
Marked Pipe Sample: XTD ASTM A312 C4 SEAMLESS 42.2x 3.56*6000MM HEAT NO. 2023121205A15
C-4 2.4610 NiMo16Cr16Ti N06455 Material Summary
Alloy C-4 / 2.4610 is an austenitic low-carbon nickel-molybdenum-chromium alloy.
Very good resistance to a wide range of corrosive media, particularly under reducing conditions. Excellent resistance to localized corrosion in halide media.
