ASTMB161 B163 Nickel 201 Alloy (UNS N02201)/2.4068 Seamless Nickel Alloy Steel Tube

HomeProducts & servicesNickel Alloy---Hastelloy/ Monel/ Inconel/Incoloy Steel tube and Pipe ASTMB161 B163 Nickel 201 Alloy (UNS N02201)/2.4068 Seamless Nickel Alloy Steel Tube
ASTMB161 B163 Nickel 201 Alloy (UNS N02201)/2.4068 Seamless Nickel Alloy Steel Tube

ASTMB161 B163 Nickel 201 Alloy (UNS N02201)/2.4068 Seamless Nickel Alloy Steel Tube

① STANDARD: ASTM B161/ ASTM B163/ASME SB161/ASME AB163

② OD RANGE : 6-257 MM

③ THICKNESS RANGE: 1-35 MM

Nickel 201 Alloy (UNS N02201)/2.4068 Chemical Composition

Grade

Ni

Cu

Fe

Mn

C

Si

S

UNS N02200
≥99.00
≤0.25
≤0.40
≤0.35
≤0.015
≤0.35
≤0.01

UNS N02201

≥99.00

≤0.25

≤0.40

≤0.35

≤0.02

≤0.35

≤0.01


Note:
1.Element shall be determined arithmetically by difference.


Nickel 201 Alloy (UNS N02201)/2.4068 Mechanical Properties

Grade

Condition

Tensile Strength

Yield Strength

Elongation(%)

N02201

Annealed

≥50(345)ksi(MPa)

≥12(83)ksi(MPa)

≥40

N02201

Stress-relieved

≥60(414)ksi(MPa)

≥30(207)ksi(MPa)

≥15

N02201 OD≤127MM

Annealed

≥50000(380)psi(MPa)

≥12000(80)psi(MPa)

≥35

N02201 OD>127MM

Annealed

≥50000(345)psi(MPa)

≥10000(70)psi(MPa)

≥40

N02201

Stress-relieved

≥60000(415)psi(MPa)

≥30000(205)psi(MPa)

≥15

the ASTM B161 ASTMB163 Nickel alloy seamless tube and pipe tolerance

Nickel 201 Alloy (UNS N02201)/2.4068 Applications

Used primarily for parts requiring excellent corrosion and strong magnetic properties such as:

One of our Services--Testing

  • EN 10204/3.1B, EN 10204 3.1 and EN 10204 3.2 Material Test Certificates (MTC)
  • Raw Materials Certificate
  • 100% Radiography Test Report
  • 100% PMI
  • Heat Treatment Charts
  • Third Party Inspection Report
  • Surface roughness and size measurement
  • Manufacturer Test Certificate( Impact Testing, Flatten, Spin,Curve, Hardness, Intergranular ,Point corrosions, Grain size, ET,UT, HT...)
  • Laboratory Test Certificate from Govt. Approved Lab
  • ......

One of our Services--End of Pipe and Tube

  • BE : Beveled end
  • BBE : Bevel both ends
  • BLE : Bevel large end
  • BSE : Bevel small end
  • TOE / POE = Treaded One End / Plain One End
  • TOE / BOE = Treaded One End / Beveled One End
  • POE / BOE = Plain One End / Beveled One End
  • TBE = Treaded Both Ends
  • PBE = Plain Both Ends

One of our Services--Packing

  • Ply Wooden Boxes
  • PE Fabric Bundles
  • Standard seaworthy export packing
  • Plastic Bags, or as required

One of our Services--Marking

  • Supplier / Manufacturer Name or Custom Logo - on request
  • Specification
  • Material Grade
  • Nominal Size
  • Schedule or Wall Thickness
  • Method of Manufacturing (Seamless or Welded)
  • Heat Number

Marked Pipe Sample: XTD ASTM B163  UNS N02201 SEAMLESS 42.2x 3.56*6000MM HEAT NO. 2023121205A15

Nickel 201 Alloy (UNS N02201)/2.4068 Material Summary

Nickel 201 alloy is a commercially pure wrought alloy having properties similar to that of nickel 200 alloy, but with a lower carbon content to avoid embrittlement by inter-granular carbon at high temperatures.

It is resistant to acids and alkalis, and dry gases at room temperature.

Alloy 201 is a wrought commercially pure Nickel with a maximum carbon level of 0.02%. This alloy provides highly ductile mechanical properties across a wide temperature range.It provides corrosion resistance in neutral to moderately reducing environments. Nickel 201 is ferromagnetic. It provides high thermal and electrical conductivity in comparison to nickel-base alloys, stainless and low alloy steels. Because of its low carbon content (.02% max.) Nickel 201 may be considered for service above 600 °F (316 °C), where alloy 200 with higher carbon content is not recommended.
