ASTMB161 B163 Nickel 201 Alloy (UNS N02201)/2.4068 Nickel Alloy Steel Seamless Pipe and Tube-Zhejiang Xintongda Special Steel Manufacturing Co., Ltd

Nickel 201 Alloy (UNS N02201)/2.4068 Chemical Composition

Grade	Ni	Cu	Fe	Mn	C	Si	S
UNS N02200	≥99.00	≤0.25	≤0.40	≤0.35	≤0.015	≤0.35	≤0.01
UNS N02201	≥99.00	≤0.25	≤0.40	≤0.35	≤0.02	≤0.35	≤0.01

Note:

1.Element shall be determined arithmetically by difference.

Nickel 201 Alloy (UNS N02201)/2.4068 Mechanical Properties

Grade	Condition	Tensile Strength	Yield Strength	Elongation(%)
N02201	Annealed	≥50(345)ksi(MPa)	≥12(83)ksi(MPa)	≥40
N02201	Stress-relieved	≥60(414)ksi(MPa)	≥30(207)ksi(MPa)	≥15
N02201 OD≤127MM	Annealed	≥50000(380)psi(MPa)	≥12000(80)psi(MPa)	≥35
N02201 OD>127MM	Annealed	≥50000(345)psi(MPa)	≥10000(70)psi(MPa)	≥40
N02201	Stress-relieved	≥60000(415)psi(MPa)	≥30000(205)psi(MPa)	≥15

the ASTM B161 ASTMB163 Nickel alloy seamless tube and pipe tolerance

Nickel 201 Alloy (UNS N02201)/2.4068 Applications

Used primarily for parts requiring excellent corrosion and strong magnetic properties such as:

lead wires
battery components
transducers
sparking electrodes
heat exchangers
implantable battery anode/connector tabs for CRM and Neurostimulation devices
stamped or etched fabrications

One of our Services--Testing

EN 10204/3.1B, EN 10204 3.1 and EN 10204 3.2 Material Test Certificates (MTC)
Raw Materials Certificate
100% Radiography Test Report
100% PMI
Heat Treatment Charts
Third Party Inspection Report
Surface roughness and size measurement
Manufacturer Test Certificate( Impact Testing, Flatten, Spin,Curve, Hardness, Intergranular ,Point corrosions, Grain size, ET,UT, HT...)
Laboratory Test Certificate from Govt. Approved Lab
......

One of our Services--Packing

Ply Wooden Boxes
PE Fabric Bundles
Standard seaworthy export packing
Plastic Bags, or as required

One of our Services--Marking

Supplier / Manufacturer Name or Custom Logo - on request
Specification
Material Grade
Nominal Size
Schedule or Wall Thickness
Method of Manufacturing (Seamless or Welded)
Heat Number

Marked Pipe Sample: XTD ASTM B163 UNS N02201 SEAMLESS 42.2x 3.56*6000MM HEAT NO. 2023121205A15

Nickel 201 Alloy (UNS N02201)/2.4068 Material Summary

Nickel 201 alloy is a commercially pure wrought alloy having properties similar to that of nickel 200 alloy, but with a lower carbon content to avoid embrittlement by inter-granular carbon at high temperatures.

It is resistant to acids and alkalis, and dry gases at room temperature.

Alloy 201 is a wrought commercially pure Nickel with a maximum carbon level of 0.02%. This alloy provides highly ductile mechanical properties across a wide temperature range.It provides corrosion resistance in neutral to moderately reducing environments. Nickel 201 is ferromagnetic. It provides high thermal and electrical conductivity in comparison to nickel-base alloys, stainless and low alloy steels. Because of its low carbon content (.02% max.) Nickel 201 may be considered for service above 600 °F (316 °C), where alloy 200 with higher carbon content is not recommended.

Standard download

ASTM B161 Standard Specification for Nickel Seamless Pipe and Tube

ASTM B163 Standard Specification for Seamless Nickel and Nickel Alloy Condenser and Heat Exchanger Tube
